Submersible Jet Aerator

Product Description

Submersible Jet Aerator by ArCh Enviro is a high performance aeration system designed to provide efficient mixing and oxygen transfer in wastewater treatment plants It is compact energy efficient and suitable for continuous operation in both municipal and industrial treatment facilities The aerator is widely used for biological oxidation homogenization and sludge stabilization in sewage treatment plants and effluent treatment plants

The SCL model is equipped with removable expulsion channels which improve aeration coverage and provide greater flexibility during maintenance activities The system can be installed and serviced without emptying the tank making it ideal for plants operating under variable conditions

Key Features

Efficient mixing and oxygen transfer for improved treatment performance
Removable expulsion channels in SCL model for enhanced aeration coverage
Compact design with easy installation
No requirement to drain tanks during operation or maintenance
Low maintenance and reliable performance
Designed for continuous operation
Corrosion resistant stainless steel construction
Available in multiple power ranges suitable for different applications

Applications

Sewage Treatment Plants
Effluent Treatment Plants
Homogenization tanks
Biological oxidation tanks
Sludge stabilization systems
Industrial wastewater treatment facilities

Technical Specifications

Power rating from one point one kilowatt to eighty kilowatt
Operating speed fourteen fifty revolutions per minute
Installation type submersible vertical mounting
Aeration method radial air dispersion
Expulsion channel fixed in SC model and removable in SCL model
Material of construction stainless steel three zero four or three one six
Application range municipal and industrial wastewater treatment

Working Principle

The SC SCL Submersible Aerator operates by drawing atmospheric air into the system and dispersing it radially into the wastewater A motor driven impeller generates strong water movement which mixes air and wastewater effectively The SCL model includes extended removable expulsion channels that allow uniform air distribution across the tank ensuring efficient aeration even in large treatment basins

This radial aeration process enhances oxygen transfer and supports microbial activity required for effective breakdown of organic matter

Operational Advantages

No shutdown or tank emptying required during maintenance
Easy retrofitting in existing aeration tanks
Stable operation under varying load conditions
Quiet performance with minimal vibration
Long service life with low operating and maintenance cost

Why Choose ArCh Enviro

Indigenously developed aeration systems designed for Indian wastewater conditions
Extensive experience in sewage and effluent treatment projects
High quality stainless steel construction for long term corrosion resistance
End to end technical support from design to after sales service
Commitment to reliable efficient and sustainable wastewater solutions

Frequently Asked Questions FAQs

1.What is the difference between SC and SCL models ?
The SCL model includes removable expulsion channels that improve air distribution and simplify maintenance while the SC model has fixed channels.

2.Is it necessary to empty the tank during installation or servicing ?
No the submersible design allows installation and maintenance without draining the tank.

3.What applications is this aerator best suited for ?
It is ideal for sewage and effluent treatment tanks requiring effective mixing aeration biological treatment and sludge stabilization.

4.What materials are used for construction ?
The aerator is manufactured using high grade stainless steel three zero four or three one six for superior corrosion resistance.
